| Max. paper size(mm) | 1200(W) x 1200(L) |
| Min. paper size(mm) | 350(W) x 400(L) |
| Paper thickness(g/㎡) | 200-600 |
| Machine speed(m/min) | 25-100 |
| Power(kw) | 46 |
| Weight(kg) | 7800 |
| Machine size(mm) | 18760(L) x 1900(W) x 1800(H) |
The paper feeding speed can reach 10,000 sheets per hour. This feeder adopts 4 feeder suckers and 4 feeder blowers. With an accurate feeder, the new designed glazing machine automatically and continuously feeds paper, ensuring the smooth conveying of different sizes’ paper. Besides, this machine is provided with a double-sheet detector. With a stock table, the paper feeding unit can add paper without stopping the machine, which ensures continuous production.
The first unit is the same as the second one. If add water then the unit can be used to remove printing powder. The second unit is a three-roller design, whose rubber roller adopts particular material so that it can evenly coat product with good effect. And it fits for water-based/oil-based oil and blister varnish, etc. The unit can be conveniently adjusted on one-side.
The motor adopts Variable-frequency Drive, which is stable, energy-saving and safe.
What is the max paper feeding speed of the HSG-120D machine?
The paper feeding speed of the HSG-120D can reach up to 10,000 sheets per hour.
What paper size and thickness ranges does the HSG-120D support?
It supports a maximum paper size of 1200(W) x 1200(L) mm and a minimum paper size of 350(W) x 400(L) mm. The compatible paper thickness ranges from 200 to 600 g/㎡.
How does the paper feeder achieve continuous production without stopping?
Equipped with a stock table, the paper feeding unit enables operators to add paper without needing to stop the machine, ensuring non-stop production.
What is the function of the first unit when water is added?
If water is added to the first unit, it can be utilized effectively to remove printing powder from the paper surface.
What coatings are compatible with the second unit?
The three-roller second unit is designed to fit water-based oil, oil-based oil, and blister varnish, featuring a rubber roller made of specialized materials for even coating application.
What drive system is used in the machine's motor?
The motor uses a Variable-frequency Drive (VFD), providing operation that is stable, energy-saving, and safe.
